QP005A-QP02A - North American Plug 3 poles 10-13-15A straight
North American cordsets
QP005A-QP02A - North American Plug 3 poles 10-13-15A straight
North American cordsets
Cordset data:
According approvals
UL 817 (Nema 5-15P)
Rating voltage
125V
Rating current
10-13-15A
Protection degree
IP 20
External insulation
PVC
Terminals type
nichel plated brass_crimped connection
Cable exit
straight
Cable type and section:
HPN AWG14
HPN AWG16
HPN AWG18
SJ-14AWG
SJ-16AWG
SJ-18AWG
SJO-14AWG shielded
SJO-16AWG
SJO-16AWG shielded
SJO-18AWG
SJOW-12AWG
SJOW-14AWG
SJOW-16AWG
SJOW-18AWG
SJT-14AWG
SJT-16AWG
SJT-18AWG
SJTW 14AWG
SJTW 16AWG
SJTW 18AWG
SPT-1 16AWG
SPT-1 18AWG
SPT-2 16AWG
SPT-2 18AWG
Approvals:
